PARAPENTE  APCO THRUST
VOILES - PARAPENTES

THRUST

La Nouvelle Aile Spéciale Paramoteur d'APCO

Prix Spéciaux  Air et Aventure : THRUST S / M : 2400 €
                                                   THRUST L : 2500 €
                                                      THRUST XL : 2650 €



THRUST Colour Options
No.
Bottom
Top
1
2
3
4
5
6
7
8
9
10
11



DESIGN FEATURES
  • Diagonal rib structure
  • Split A riser
  • All metal parts Stainless Steel or Aluminium
  • Eliptical planform
  • Heavy duty Technora lines
  • Double coated siliconised cloth
  • HIT Valves
  • Universal riser + accelerator and trim tabs to fit any frame (for paramotor version) or standard
  • paragliding riser
  • Top surface color design – fresh and attractive

THRUST - Technical Data

SIZE

 Small

Medium

Large

X-Large

Cells

42

44

46

48

Area

[m 2 ]

 27.3

29.3

31.3

33.3

Area (Projected)

[m 2 ]

 23.4

25.2

26.9

28.6

Span incl. Stabiliser

[m]

 11.58

12.2

12.9

13.5

Span (Projected)

[m]

 9.32

9.85

10.4

10.9

A/R

 4.91

5.08

5.31

5.47

A/R (Projected)

 3.71

3.85

4.02

4.15

Take off weight (All up pilot + paramotor)

[kg]

 70-115

85-135

100-155

110-180

Pilot weight all up for free flight

[kg]

 65-85

80-100

95-120

110-140

Weight of canopy

[kg]

 6.5

6.9

7.3

7.6

Root cord

[m]

 3.03

3.05

3.05

3.05

Tip cord

[m]

 0.58

0.58

0.58

0.58
Length of lines on B

[m]

 6.6 7.0 7.4 7.7

Total length of lines

[m]

 407

421

441

481



Performance Data

V-min.

21 km/h

V-trim

37 km/h

V-max. P/M version

50 km/h

V-max. P/G version

45 Km/h

Min Sink ( at optimum wing loading)

1.1 m/s



LINES



Material

Diameter

Strength

Top

Dyneema

1.1 mm

95 Kg

Middle

Kevlar

1.2 mm / 1.8 mm

110 kg / 220 Kg

Bottom

Kevlar

1.8 mm / 1.9 mm

220 kg / 320 Kg

FABRIC

Sail Cloth

46gr/m 2 "Zero Porosity" Ripstop Nylon
(Double Siliconized)

Rib Reinforcement

80gr/m 2 Mylar (Trilam)

Warranty

3 Years / 250 hours



CERTIFICATION

THRUST SMALL STANDARD

THRUST MEDIUM

STANDARD

THRUST LARGE

STANDARD

THRUST EXTRA LARGE

STANDARD




Thrust 3D Plan Form
Thrust 3D Plan Form Large View
