PARAPENTE  SKYWALK

DONNEES TECHNIQUES SKYWALK

XS	S	M	L
35	35	35	35	Cells
24,5	26,6	28,20	31,10	Area (m²)
21,85	23,72	25,15	27,24	Area (projected)
10,6	11,04	11,37	11,94	Span
8,87	8,87	9,42	9,89	Wingspan proj.
4,58	4,58	4,58	4,58	Aspect Ratio
3,53	3,53	3,53	3,53	Aspect Ratio proj.
640	670	6,90	7,25	Line length (m)
63	66	68	71	Min. profile depth (cm)
282	294	302	318	Max. profile depth (cm)
5,4	5,7	6,0	6,5	Weight of Glider (kgs)
60 - 80 kg	75 - 95 kg	90 - 110 kg	100 - 130 kg	Poids Total Volant
1	1	1	1	DHV Class
nein/no	nein/no	ja/yes	ja/yes	Motor Certified
ja/yes	ja/yes	ja/yes	ja/yes	WInch-towing

XS	S	M	L
46	46	46	46	Cells
24,4	26,5	28,3	31,4	Area (m²)
21,85	23,73	25,35	28,1	Area (projected)
11,4	11,4	11,89	12,52	Span
9,2	9,2	9,91	10,4	Wingspan proj.
5	5	5	5	Aspect Ratio
3,9	3,9	3,9	3,9	Aspect Ratio proj.
682	711	735	774	Line length (m)
53	55	57	60	Min. profile depth (cm)
275	287	296	312	Max. profile depth (cm)
60 - 80 kg	75 - 95 kg	90 - 110 kg	100 - 130 kg	Poids Total Volant
1 - 2	1 - 2	1 - 2	1 - 2	DHV Class
no/nein	no/nein	yes/ja	yes/ja	Motor Certified
yes/ja	yes/ja	yes/ja	yes/ja	WInch-towing

XS	S	M	L
54	54	54	54	Cells
23,60	26,20	28,30	31,10	Area (m²)
21,15	23,47	25,35	27,86	Area (projected)
11,19	11,78	12,25	12,84	Span
9,40	9,90	10.29	10,97	Wingspan proj.
5,3	5,3	5,3	5,3	Aspect Ratio
4,18	4,18	4,18	4,18	Aspect Ratio proj.
6,90	7,25	7,55	7,90	Line length (m)
48	51	53	55	Min. profile depth (cm)
266	280	291	305	Max. profile depth (cm)
5,7	6,2	6,5	7,0	Weight of Glider (kgs)
60 - 80 kg	75-95 kg	90 - 110 kg	105 - 130 kg	Poids Total Volant
2	2	2	2	DHV Class
nein/no	nein/no	ja/yes	ja/yes	Motor Certified
ja/yes	ja/yes	ja/yes	ja/yes	WInch-towing
